Layout Drawing of Auto Short Cycle Melamine Laminating Line ( From Length Side Feeding )
Sumto is specialized for automatic particle board/ MDF/ melamine paper pre lamination short cycle hot press line. As we can provide different plan according to customer's request. Automatic line will help customers save labor and save time, increase capacity.
Before shipping, the automatic melamine lamination short cycle hot press line will be tested strictly, it is not same to half auto short cycle hot press which always can fix the problem by manual. Each steps have to be confirmed accurated then can work well.
Our machine choose international famous brand spare parts, can use for long time and work in good condition, it is also easy find in customer's country. |
|
| |
| No.1 - Auto short cycle hot press line with cleaning, trimming, cooling machine ( I Model ) |
 |
| 1- Fork lifting stacker 2- Feeding belt 3- Board pusher 4- Cleaning brusher 5- Alignment table 6- Board carrier 7- Feeding conveyor 8- Short cycle hot press 9- Out feeder 10- Feeding belt 11- Four side edge trimming 12- Cooler feeder 13- Board cooling machine 14- Cooler out feeder 15- Board carrier 16- Finished board stacker |
| |
| No.2 - Auto short cycle hot press line with cleaning, trimming, cooling machine ( L Model ) |
 |
| 1- Fork lifting stacker 2- Feeding belt 3- Board pusher 4- Cleaning brusher 5- Alignment table 6- Board carrier 7- Feeding conveyor 8- Short cycle hot press 9- Out feeder 10- Feeding belt 11- Four side edge trimming 12- Cooler feeder 13- Board cooling machine 14- Cooler out feeder 15- Board carrier 16- Finished board stacker A 17- Finished board stacker B |
| |
|
| |
| No.3 - Auto short cycle hot press line with cleaning, trimming, cooling machine ( U Model ) |
 |
| 1- Fork roller stacker 2- Lifting roller 3- Board pusher 4- Cleaning brusher 5- Alignment table 6- Paper frame 7- Board carrier 8- Feeding conveyor 9- Short cycle hot press 10- Out feeder 11- Feeding belt 12- Four side edge trimming 13- Cooler feeder 14- Board cooling machine 15- Transition roller conveyor 16- Board cooling machine 17- Cooler out feeder 18- Alignment table 19- A grade stacker 20-Roller stacker 21- B grade stacker 22- Board carrier |
| |
| |
